Print Method: Direct Thermal
Resolution: 203 dpi (dots per inch)
Maximum Print Width: 104mm (4.09 inches) / 4.23 inches (108mm)
Maximum Print Length: 250mm (9.84 inches) / 300mm (11.81 inches) – Note: There’s a slight variation in maximum print length reported across sources, but generally around 250-300mm.
Printing Speed: Typically 127mm/s (5 inches/s), with some models/options up to 150mm/s (6 inches/s)
Media Type: Label paper, Bottom black mark paper, Continuous paper, Fanfold paper, Gap labels.
Media Width: Minimum 26.7mm (1.05 inches) to Maximum 120mm (4.72 inches)
Media Thickness: 0.058mm – 0.18mm (some sources mention 0.06mm-0.18mm)
Maximum Paper Roll Diameter: φ130mm (5.12 inches)
Reel Inner Diameter (Core Size): φ25.4mm (1 inch), φ38mm (1.5 inches)
Interface Options (Commonly Available):
- USB (Standard)
- USB + Bluetooth
- USB + LAN (Ethernet) + Serial (RS232)
- USB + WiFi
Programming Language (Commands): TSPL (standard), sometimes also supports CPCL and ZPL (optional/customized)
Memory:
- RAM: Typically 8MB (some sources mention 256MB for RP410A-AiRPrint model, or 2MB/4MB depending on interface)
- FLASH: Typically 4MB (some sources mention 256MB for RP410A-AiRPrint model, or 2MB/4MB depending on interface)
Barcodes Supported:
- 1D (One-dimensional): Code39, Code93, Code128, ITF, ITF14, EAN-8, EAN-13, UPC-A, UPC-E, Codabar, MSI, PLESSEY, CPOST, Code11.
- 2D (Two-dimensional): QR Code, PDF417 (often optional)
Drivers: Supports Windows (XP, 7, 8, 10, 11), Linux, MacOS, Android, iOS.
Software: Includes label design software (e.g., NiceLabel SE) for PC, and often supports mobile apps.
Power Supply: Input: AC 100-240V, 50/60Hz; Output: DC 24V/2.5A
Sensors: Seam mark detection, black mark detection, paper shortage detection, backflow detection, cover opening detection, print head temperature detection.
Features:
- Label off intelligent function
- Bad point detection
- Fast printing
- Superior cooling performance for high workload printing
- Re-printing function (to avoid data loss or omissions)
- Automatic paper positioning after cover is opened/closed
- Automatic paper recognition
Dimensions (L x W x H): Approximately 217mm x 182mm x 172mm
Weight: Approximately 1.4 kg – 1.72 kg (varies slightly by specific model/accessories)
Operating Environment: Temperature: 0°C to 40°C (32°F to 104°F); Humidity: 20% to 90% (non-condensing)
Accessories: Standard package usually includes power adapter, power cord, USB data cable, and quick installation guide. External media holder may be optional.
